Name	Diameter (mm)		Weight* (kg)	Name	Diameter (mm)		Weight* (kg)
	∅D	TOL			∅D	TOL
MU-3	3	+0.3 / +0.6	0.045	MU-15	15	+0.3 / +0.6	0.916
MU-4	4	+0.3 / +0.6	0.078	MU-16	16	+0.3 / +0.6	1.015
MU-5	5	+0.3 / +0.6	0.120	MU-17	17	+0.3 / +0.6	1.140
MU-6	6	+0.3 / +0.6	0.155	MU-18	18	+0.3 / +0.6	1.270
MU-7	7	+0.3 / +0.6	0.210	MU-20	20	+0.3 / +0.6	1.557
MU-8	8	+0.3 / +0.6	0.270	MU-22	22	+0.4 / +0.7	1.876
MU-9	9	+0.3 / +0.6	0.330	MU-24	24	+0.4 / +0.7	2.242
MU-10	10	+0.3 / +0.6	0.410	MU-25	25	+0.5 / +0.8	2.419
MU-11	11	+0.3 / +0.6	0.484	MU-26	26	+0.5 / +0.8	2.645
MU-12	12	+0.3 / +0.6	0.580	MU-28	28	+0.5 / +0.8	3.079
MU-13	13	+0.3 / +0.6	0.684	MU-30	30	+0.5 / +0.8	3.500
MU-14	14	+0.3 / +0.6	0.790	MU-32	32	+0.5 / +0.8	3.950

* The weights are approximate.
All rods are Full Length
For custom sizes please contact us

Length: 330mm     Tolerance: +3mm
